H&R Trak+ 20mm DRM Wheel Adaptor – 4x100 Bolt Pattern, 54.1mm Center Bore, 12x1.5 Stud Thread - Wheel Spacers & Adapters - H&R at Garage 56 Engineering
H&R Trak+ 20mm DRM Wheel Adaptor – 4x100 Bolt Pattern, 54.1mm Center Bore, 12x1.5 Stud Thread - Wheel Spacers & Adapters - H&R at Garage 56 Engineering

H&R TRAK+ 20mm DRM Wheel Spacers (Pair) - NA/NB Miata (90-05) & ND MX-5 (16+)

H&R TRAK+ DRM wheel spacers, 20 mm thick, for the 1990-1997 Mazda Miata (NA), 1999-2005 Miata (NB)...
Vendor: H&R
SKU: HRS4024542
Availability: Available to Order
Product type: Wheel Spacers & Adapters
$206.96
$229.95
$206.96
Save $22.99
10 customers are viewing this product
H&R Trak+ 20mm DRM Wheel Adaptor – 4x100 Bolt Pattern, 54.1mm Center Bore, 12x1.5 Stud Thread - Wheel Spacers & Adapters - H&R at Garage 56 Engineering

Vendor: H&R

H&R TRAK+ 20mm DRM Wheel Spacers (Pair) - NA/NB Miata (90-05) & ND MX-5 (16+)

$229.95 $206.96

Vendor: H&R

H&R TRAK+ 20mm DRM Wheel Spacers (Pair) - NA/NB Miata (90-05) & ND MX-5 (16+)

$229.95 $206.96

H&R TRAK+ DRM wheel spacers, 20 mm thick, for the 1990-1997 Mazda Miata (NA), 1999-2005 Miata (NB) and 2016-2023 MX-5 Miata (ND), including the RF. They bolt to the hub and carry their own wheel studs, keeping the car's 4/100 bolt pattern. Sold as a pair.

  • Thickness: 20 mm per spacer; sold as a pair (two spacers)
  • DRM type: bolts to the hub with the existing wheel studs and special nuts (included); the wheel then bolts to new wheel studs in the spacer
  • Bolt pattern 4/100, center bore 54.1 mm, stud thread 12x1.5
  • Hubcentric with full-contact hub mounting
  • Made from H&R's proprietary alloy, which H&R describes as lighter and higher in tensile strength than 6061-T6 billet aluminum

Fitment: 1990-1997 Mazda Miata (NA), 1999-2005 Mazda Miata (NB), 2016-2023 Mazda MX-5 Miata (ND) soft top and 2017-2023 MX-5 Miata RF. Not for the 2006-2015 MX-5 (NC), which uses a 5/114.3 bolt pattern. If the spacer is thinner than the length of the standard studs, the wheels must have small cavities in the mounting pad. With wheels that have no cavities, the standard studs should be shortened so they do not extend beyond the spacer.

Part number: H&R 4024542

This Part Fits:

Year Make Model Submodel
1990-1997 Mazda Miata All
1999-2005 Mazda Miata All
2016-2023 Mazda MX-5 Miata All
