H&R TRAK+ 20mm DRA Wheel Adapters (Pair, 4/100 to Audi 4/108) - NA/NB Miata (90-05)

H&R TRAK+ DRA wheel adapters, 20 mm thick, for the 1990-1997 Mazda Miata (NA) and 1999-2005 Miata...
Vendor: H&R
SKU: HRS402345411
Availability: Available to Order
Product type: Wheel Spacers & Adapters
$170.55
$189.50
$170.55
Save $18.95
10 customers are viewing this product
H&R Trak+ 20mm Wheel Adapter – 4/108 to 4/100, 57.1mm CB, 12x1.5 to 14x1.5 Stud Thread - Wheel Spacers & Adapters - H&R at Garage 56 Engineering

H&R

H&R TRAK+ 20mm DRA Wheel Adapters (Pair, 4/100 to Audi 4/108) - NA/NB Miata (90-05)

$189.50 $170.55
H&R Trak+ 20mm Wheel Adapter – 4/108 to 4/100, 57.1mm CB, 12x1.5 to 14x1.5 Stud Thread - Wheel Spacers & Adapters - H&R at Garage 56 Engineering
H&R Trak+ 20mm Wheel Adapter – 4/108 to 4/100, 57.1mm CB, 12x1.5 to 14x1.5 Stud Thread - Wheel Spacers & Adapters - H&R at Garage 56 Engineering

H&R

H&R TRAK+ 20mm DRA Wheel Adapters (Pair, 4/100 to Audi 4/108) - NA/NB Miata (90-05)

$189.50 $170.55
Product Details

H&R TRAK+ DRA wheel adapters, 20 mm thick, for the 1990-1997 Mazda Miata (NA) and 1999-2005 Miata (NB). They change the wheel bolt pattern so that Audi wheels with a 4/108 pattern and 57.1 mm center bore can be mounted on the car's 4/100 hubs. Sold as a pair.

  • Thickness: 20 mm per adapter; sold as a pair (two adapters)
  • Vehicle side: bolt pattern 4/100, center bore 54.1 mm, thread 12x1.5
  • Wheel side: bolt pattern 4/108, wheel center bore 57.1 mm, wheel thread 14x1.5
  • DRA type: H&R defines the DRA series as bolting to the hub with special wheel bolts (included) and providing new threaded holes for the wheel bolts
  • Hubcentric spacers that change the bolt pattern for different wheel fitments
  • Made from H&R's proprietary alloy, which H&R describes as lighter and higher in tensile strength than 6061-T6 billet aluminum

Fitment: 1990-1997 Mazda Miata (NA) and 1999-2005 Mazda Miata (NB). For mounting Audi-pattern wheels (4/108, 57.1 mm center bore) only; the wheels fasten with 14x1.5 wheel bolts, not the factory lug nuts. Not for wheels with the factory 4/100 pattern. Not for NC or ND cars.

Part number: H&R 402345411

This Part Fits:

Year Make Model Submodel
1990-1997 Mazda Miata All
1999-2005 Mazda Miata All
